 Pipe Making Machine,  165
Feedback Form
Feedback Form

Pipe Making Machine, 165

165 high frequency longitudinal welded pipe production line is designed to produce welded pipes of 76mm-165mm in OD and 2.0mm-6.0mm in wall thickness, as well as corresponding square and rectangular pipes. This pipe making machine is extensively used for making welded pipes for industries like metallurgy, construction, transportation, machinery and vehicle, etc.

Basic technical information
Raw Material: The pipe making machine is made using materials like carbon steel and low alloy steel coil
Coil ID: 580-700mm
Coil OD: Max 1800mm
Coil Weight: 6t
Production Speed : 20-50 m/min
Production capacity: 25,000ton/year
Direction : left or right decided by customers.
Line Area : 85m(length) ×7m (width)
Tube Bottom Passline (Above floor level) : +850 mm

Specifications of pipe making machine, 165

Model Specification(mm) Thickness (mm) Mill Installed Capacity(kw) Line Area(m) - programmable Working Speed (M/min.)
Circular Rectangular & Square
165 Ф76-Ф165 60mm×60mm - 130mm×130mm 2-6 220KW 85m*7m 50

We is an experienced pipe making machine manufacturer in China. We provide customers with a wide array of tube making machine products, including welded pipe making machine, stainless steel pipe making machine, and more.
Feel free to contact us for more information about our products. We are certain you will be satisfied with our products and services.
