 Pipe Making Machine,  20
Feedback Form

Pipe Making Machine, 20

We pipe production line is designed to manufacture pipe or tube used in metallurgy, construction, transportation, machinery and vehicle industries. 20 high frequency longitudinal welded pipe production line is designed to produce welded pipes of 8mm-20mm in OD and 0.5mm-1.5mm in wall thickness, as well as corresponding square and rectangular pipes.

Basic technical information
Raw Material: This pipe production line primarily adopts materials like carbon steel and low alloy steel coil.
Coil ID: 450-520mm
Coil OD: Max 1200mm
Coil Weight: 1t
Production Speed: 20-100 m/min
Production capacity: 10,000ton/year
Direction: left or right, upon customers' requirement.
Line Area: 40m(length) ×3.8m (width)
Tube Bottom Passline (Above floor level): 800 mm

To make customers better understand We 20 high frequency longitudinal welded pipe production line, we offer the following technical specifications. For more detailed information, please contact us directly.

Model Specification(mm) Thickness (mm) Mill Installed Capacity(kw) Line Area(m) - programmable Working Speed (M/min.)
Circular Rectangular & Square
20 Ф8-Ф20 10mm×10mm -15mm×15mm 0.5-1.5 50KW 40m*3.8m 100

As a China welded pipe making machine manufacturer, We provides a comprehensive range of tube making machine products, including abroach cold rolled section steel forming machine, precision pipe mill, and more. Our company has received the ISO9001:2008 certificate. We are located in Shijiazhuang City, Hebei Province, which provides us with convenient transportation. This results in reduced transportation fees for our raw materials, as well as the freight charges for our customers.
For more detailed information, please continue browsing our website or call us right now!
