Stainless Steel Pipe Making Machine

Stainless steel pipe making machine is designed for manufacturing stainless steel straight welded pipe for metallurgy, construction, transportation, machinery and vehicle industries. To be specific, the stainless steel pipe production line can produce round pipe, square and rectangular tube, as well as section steels through cold rolled forming and high frequency welding technology.

This pipe making machine adopts long steel strip as the material to manufacture steel pipes according to requested size by cold rolled forming and argon arc welding method.





Technical specifications

Model Specification(mm) Thickness (mm) Mill Installed Capacity(kw) Line Area(m) - programmable
Circular Rectangular & Square
SS20 Ф8-Ф20 10mm×10mm - 15mm×15mm 0.5-1.5 50KW 40m*3.8m
SS32 Ф10-Ф32 10mm×10mm -25mm×25mm 0.3-2.0 50KW 45m*4m
SS50 Ф20-Ф50 15mm×15mm - 40mm×40mm 0.8-3.0 65KW 50m*4m
SS76 Ф32-Ф76 25mm×25mm - 60mm×60mm 1.2-4.0 120KW 70m*5m
SS89 Ф42-Ф89 25mm×25mm - 70mm×70mm 1.5-4.5 150KW 72m*5.5m
SS114 Ф48-Ф114 40mm×40mm - 90mm×90mm 1.5-4.5 160KW 78m*6m
SS140 Ф60-Ф140 50mm×50mm - 110mm×110mm 2-5 180KW 80m*6.5m
SS165 Ф76-Ф165 60mm×60mm - 130mm×130mm 2-6 220KW 85m*7m
SS219 Ф89-Ф219 70mmx70mm - 170mm×170mm 2-8 280KW 100m*9m
SS273 Ф114-Ф273 90mm×90mm - 210mm×210mm 3-10 350KW 120m*10m
SS325 Ф140-Ф325 90mm×90mm - 250mm×250mm 4-12.7 430KW 130m*11m
SS377 Ф165-Ф377 130mmx130mm - 280mmx280mm 4-14 580KW 145m*13m
SS406 Ф219-Ф406 170mm×170mm - 330mm×330mm 6-16 880KW 160m*16m
SS508 Ф273-Ф508 210mmx210mm - 400mmx400mm 6-18 1000KW 300m*30m
