 Pipe Making Machine,  377
Feedback Form
Feedback Form

Pipe Making Machine, 377

377 high frequency longitudinal welded pipe production line is designed to produce welded pipes of 165mm-377mm in OD and 4.0mm-14.0mm in wall thickness, as well as corresponding square and rectangular pipes which are ideal for use in industries like metallurgy, construction, transportation, machinery and vehicle manufacturing, etc.

Basic technical information
Raw Material: 377 longitudinal welded pipe production line adopts carbon steel and low alloy steel coil as the primary material.
Coil ID: 580-760mm
Coil OD: Max 2100mm
Coil Weight: 25t
Production Speed: 35 m/min
Production capacity: 120,000ton/year
Direction: left or right decided by customers.
Line Area: 145m(length) ×13m (width)
Tube Bottom Passline (Above floor level) : +950 mm

Specifications of longitudinal welded pipe production line, 377

Model Specification(mm) Thickness (mm) Mill Installed Capacity(kw) Line Area(m) - programmable Working Speed (M/min.)
Circular Rectangular & Square
377 Ф165-Ф377 130mmx130mm - 280mmx280mm 4-14 580KW 145m*13m 35

As an experienced longitudinal welded pipe production line manufacturer and supplier, We also offers stainless steel pipe making machine, auxiliary equipment for pipe making machine and rollers, etc. Today, our tube making machine products are reliable, durable, economical, and are very popular with customers in United States, Kazakhstan, Uzbekistan, Iran, among other countries.
Please contact us for more information. We look forward to serving you!
