89 high frequency longitudinal welded pipe making machine is designed to produce welded pipes of 42mm-89mm in OD and 1.5mm-4.5mm in wall thickness, as well as corresponding square and rectangular pipes. The pipes produced by this pipe making machine can be widely used in various industries, including metallurgy, construction, transportation, machinery, and vehicle industries, etc.
Basic technical information
Raw Material: Carbon steel coil & Low alloy steel coil
Coil ID: 550-610mm
Coil OD: Max 1600mm
Coil Weight: 4t
Production Speed: 20-70m/min
Production capacity: 22,000ton/year
Direction: left or right decided by customers.
Line Area: 72m (length) ×5.5m (width)
Tube Bottom Passline (Above floor level): +800 mm
Specifications of pipe making machine, 89
| Model | Specification(mm) | Thickness (mm) | Mill Installed Capacity(kw) | Line Area(m) - programmable | Working Speed (M/min.) | |
| Circular | Rectangular & Square | |||||
| 89 | Ф42-Ф89 | 25mm×25mm - 70mm×70mm | 1.5-4.5 | 150KW | 72m*5.5m | 70 |
As a Chinese pipe making machine manufacturer, we at We provide several types of tube making machine, including stainless steel pipe making machine, multifunctional cold rolled section steel, and more. With the advantage of superior quality and reliability, our products are in increasing demand in United States, Kazakhstan, Uzbekistan, Syria, Iran, Vietnam, Chile, Iraq, among other countries.
We welcome you to contact us for more information.
