 Pipe Making Machine,  32
Feedback Form

Pipe Making Machine, 32

32 high frequency longitudinal welded pipe production line, or simply pipe making machine, is designed to produce welded pipes of 10mm-32mm in OD and 0.3mm-2.0mm in wall thickness, as well as corresponding square and rectangular pipes.

Basic technical information
Raw Material: Carbon Steel & Low alloy steel coil
Coil ID: 450-520mm
Coil OD: Max 1200mm
Coil Weight: 1t
Production Speed: 30-100m/min
Production capacity: 10,000 ton/year
Direction: left or right decided by customers.
Line Area: 45m(length) ×4m (width)
Tube Bottom Passline (Above floor level): +800 mm

Specifications of pipe making machine, 32

Model Specification(mm) Thickness (mm) Mill Installed Capacity(kw) Line Area(m) - programmable Working Speed (M/min.)
Circular Rectangular & Square
32 Ф10-Ф32 10mm×10mm -25mm×25mm 0.3-2.0 50KW 45m*4m 100

We are a China based pipe making machine manufacturer and supplier. Through our years of experience and continued efforts of our dedicated staff, we can offer customers a great variety of quality tube making machine products, like welded pipe making machine, stainless steel pipe making machine, and others. In addition, our location in Shijiazhuang City gives us convenient transportation. This keeps our costs down, and reduces transportation costs for our customers.
Whenever you have a need for any of our products, please feel free to contact us at We Pipe Technology Development Company.
